Split Screen, Synchronised Analysis:
Current performance (Left) and Best performance (Right). Videos can be locked at a keyframe and advanced together frame-by-frame, slow motion*2*4*8*16 or full speed. In addition it is possible to Loop the video for continuous playback.

Drawing Tools:

Lines, Shapes, Arrows, Circles, Curves, Text:
all can be used to assist coaching analysis. The drawings remain overlaid as the video advances allowing relative body motion to be observed. The lines, shapes and text can be saved with the video file and recalled at a later date.

Video Calibration:

Measure Distance:
Calibrate a video file and measure any distance using the line drawing tool. (Right Click)
Coupled with the stopwatch feature this allows the measurement of Speed through gaining the Time & Distance data.

Keyframe Markers + Stopwatch:

Up to 8 keyframe markers can be set to allow specific frames to be conveniently interchanged in the main and best windows. This saves much time when analysing technique and is especially useful when using the Image Capture function. The Stopwatch measures the time in-between selected markers.

Angles:

Allows the user to create an angle of reference on the screen. There are 3 angle options: Freehand, Angle to the Vertical and Angle to the Horizontal. You can display up to 10 angles in the data table, all of which can be saved with the video file and recalled at a later date. xxxxxxxxxxx

Single Image Photo:

Take a photo; copy it to the clipboard or save it as a jpeg. Ideal for presentations or reports. Lines, angles and text are contained within the photo method as seen above.

Multiple Image Photo:

4, 6, 9, 12 and 18 Landscape or Portrait Image Photos. Take a photo; copy them to clipboard or save them as a jpeg. Ideal for presentations or reports, on screen or in print.

Video Blend: Single Background

Set the background of an individual frame and move the video on fading between both images. The intensity level of each image is varied with a scroll bar allowing small, intricate movements to be immediately noticed.

Video Blend: Multi Backgrounds



Set the background of an multiple frames, and move the video on fading between both images. The intensity level of the background images is varied with a scroll bar allowing small, intricate movements to be immediately noticed. xxxxxxx

Video Overlay:

Overlay two synchronised videos and blend both images together. The intensity level of each image is varied with a scroll bar allowing differences in technique to be immediately noticed. Ideal for comparing the differences within an individual's technique or comparing them to a best performance model.

Memo Pad & Audio Memo:

Memo Pad allows a coach, or athlete, to make written comments about a particular video file. These comments can be saved with the video file and recalled for later viewing in the FREE Quintic Player. An ideal coaching and record function.

Audio Memo enhances this feedback tool by enabling a user to record voice commentary onto any video file. Easy to use, this function requires a standard microphone plugged into the audio jack on a computer. All commentary is automatically saved with the video and played back within the FREE Quintic Player.

Quintic Premier Capture:

• 50/60 frames per second (fps) - maximum 5 minutes
• 25fps - maximum 60 minutes
• Excellent file compression.
• USB 2 or Firewire 1394 IEEE Capture.
• 5 seconds at 50 fps ~ 1MB.
• Ideal file size for email, storage or website upload.
• Full Screen option - ideal for presentations...
• Capture, Save & Compress a series of videos.
• Create a specific client folder and video file name prior to recording, easily Start & Stop recording...
• Save up to 10 videos in a row.



Quintic USB2 High-Speed LIVE Camera Capture:

• 80-250 frames per second (fps) - maximum 10 minutes
• 80 frames per second avi video capture (752 x 480 image size dimensions)
• Excellent file compression ( 5 seconds at 50 fps ~ 1MB).
• Video output via USB2 - 5m length supplied with camera.
• Ideal file size for email, storage or website upload.
• Full Screen option - ideal for presentations...
• Capture, Save & Compress a series of videos.
• Create a specific client folder and video file name prior to recording, easily Start & Stop recording...
• Create own area of interest, recording speed, shutter, iris...
• Camera comes with tripod mount with options for either a fixed 12mm or zoom 8-48mm C-Mount lens.
• C-Mount Lens adapter.
• No external power supply required.



Instant Capture:

• Live Capture from one camera ONLY (25fps).
• Provide instant feedback to the athlete or client.
• Select recording time and playback delay.
• Choose instant playback or time delayed to suit your needs.
• Playback at full, half or quarter speed.
• All videos are played back in the Main analysis window and all analysis tools are available for use.
• Save or discard the video after use.

Video Filters:

• Adjust the brightness & contrast of any video or live feed
• Flip live images (vertical & horizontal)
• Ideal for kinaesthetic feedback
• Insert a jpeg image as a watermark

• Create a watermark or text overlay for any videos
• Ideal for branding video files

Quintic Editor:

• Quintic Video Editing Suite
• 'Trim' videos to reduce size or save specific content
• Save videos as compressed files
• Unrivalled Video File Size
• Open up any video file type to edit - Convert old incompatible video files for analysis...
• Reduce the size of existing video libraries
• Improve the quality and size of existing video libraries
